Volume pricing
- 1+ pcs$0.29
- 10+ pcs$0.27
- 100+ pcs$0.26
- 500+ pcs$0.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Additional Feature
- UL RECOGNIZED
- Fall Time Typ
- 10 μs
- Pin Sayısı
- 6
- Parça Durumu
- Active
- Forward Current
- 60mA
- Number Of Elements
- 1
- Voltage Isolation
- 5000Vrms
- Collectoremitter Saturation Voltage
- 300mV
- Rise Time
- 10μs
- Optoelectronic Device Type
- TRANSISTOR OUTPUT OPTOCOUPLER
- Montaj Tipi
- Through Hole
- Current Transfer Ratiomin
- 63% @ 10mA
- Output Voltage
- 70V
- Max Output Voltage
- 70V
- Montaj
- Through Hole
- Max Input Current
- 60mA
- Terminal Kaplaması
- Matte Tin (Sn)
- Çalışma Sıcaklığı
- -55°C~100°C
- Çıkış Tipi
- Transistor with Base
- Ambalaj
- Tube
- JESD-609 Kodu
- e3
- Collector Emitter Voltage Vceo
- 70V
- Reverse Breakdown Voltage
- 6V
- Output Current Per Channel
- 150mA
- Giriş Tipi
- DC
- Input Current
- 60mA
- Fabrika Tedarik Süresi
- 17 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kılıf / Paket
- 6-DIP (0.400, 10.16mm)
- Current Transfer Ratio Max
- 125% @ 10mA
- Yayın Yılı
- 2007
- Max Power Dissipation
- 250mW
- Rise Fall Time Typ
- 5μs 5μs
- Kurşunsuz
- Lead Free
- Configuration
- SINGLE
- RoHS Durumu
- ROHS3 Compliant
- Radyasyon Dayanımı
- No
- Max Collector Current
- 150mA
- ECCN Kodu
- EAR99
- Voltage Forward Vf Typ
- 1.4V
