Volume pricing
- 1+ pcs$0.65
- 10+ pcs$0.61
- 100+ pcs$0.58
- 500+ pcs$0.54
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Forward Current
- 20mA
- Lens Transparency
- Diffused
- RoHS Durumu
- ROHS3 Compliant
- Viewing Angle
- 120°
- Yükseklik
- 1.8mm
- Millicandela Rating
- 650mcd Red, 1900mcd Green, 384mcd Blue
- Parça Durumu
- Active
- Contact Plating
- Silver
- Reach Svhc
- No SVHC
- Lens Size
- 2.30mm
- Number Of Elements
- 3
- Wavelength Peak
- 630nm Red 522nm Green 465nm Blue
- Temel Parça No
- ASMT-YT
- Min. Çalışma Sıcaklığı
- -40°C
- Yayın Yılı
- 2012
- Lens Color
- Clear
- Maks. Çalışma Sıcaklığı
- 100°C
- Pin Sayısı
- 6
- Luminous Intensity
- 384 mcd
- Configuration
- Independent
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- JESD-609 Kodu
- e4
- Boyut / Ölçü
- 3.00mm Lx2.80mm W
- Radyasyon Dayanımı
- No
- Ambalaj
- Tape & Reel (TR)
- Current Test
- 20mA Red 20mA Green 20mA Blue
- Fabrika Tedarik Süresi
- 14 Weeks
- Montaj
- Surface Mount
- Voltage Forward Vf Typ
- 2.1V Red 3.1V Green 3.1V Blue
- Optoelectronic Device Type
- TRIPLE COLOR LED
- HTS Kodu
- 8541.40.20.00
- Lens Style
- Square with Flat Top
- Renk
- Red, Green, Blue (RGB)
- Kılıf / Paket
- 6-SMD, J-Lead
- Montaj Tipi
- Surface Mount
- Wavelengthdominant
- 623nm Red 529nm Green 469nm Blue
- Reverse Voltage
- 4V
- Depth
- 3mm
