Specifications
- Operating Frequency Max
- 2500 MHz
- Montaj Tipi
- Surface Mount
- Package Equivalence Code
- SOT-343R
- Terminal Kaplaması
- Tin/Lead (Sn/Pb)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Powermax Cw
- 20dBm
- Besleme Gerilimi
- 3.3V~3.8V
- Gain
- 16.5dB
- RoHS Durumu
- Non-RoHS Compliant
- Noise Figure
- 4.2dB
- Frekans
- 0Hz~2.5GHz
- REACH Uyumluluk Kodu
- not_compliant
- Fonksiyon Sayısı
- 1
- Yayın Yılı
- 2003
- Ihs Manufacturer
- BROADCOM INC
- Current Supply
- 60mA
- Ambalaj
- Tape & Reel (TR)
- P1db
- 17.7dBm
- Technology
- BIPOLAR
- Package Description
- PLASTIC, SC-70, SOT-343, 4 PIN
- Rfmicrowave Device Type
- WIDE BAND LOW POWER
- Kılıf / Paket
- SC-82A, SOT-343
- Characteristic Impedance
- 50Ohm
- Vswrmax
- 1.5
- Package Body Material
- PLASTIC/EPOXY
- JESD-609 Kodu
- e0
- Part Life Cycle Code
- Obsolete
- ECCN Kodu
- EAR99
- Test Frequency
- 900MHz
- Risk Rank
- 5.1
- Üretici Parça No
- ADA-4743-TR1
- HTS Kodu
- 8542.33.00.01
- Rohs Code
- No
- Rf Type
- Cellular, PCS, WLL, WLAN
- Parça Durumu
- Obsolete
- Power Supplies
- 3.8V
- Construction
- COMPONENT
