Specifications
- Breaking Capacity Rated Voltage
- 50A
- Current Rating Amps
- 750mA
- Response Time
- Slow Blow
- Packing Method
- TR, 7 INCH
- Çalışma Sıcaklığı
- -55°C~125°C
- Reference Standard
- UL
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 10 Weeks
- Melting I2t
- 0.005
- Additional Feature
- PRE ARCING TIME: OPEN WITHIN 5 SEC AT 250% RATED CURRENT
- Terminal Shape
- WRAPAROUND
- Circuit Protection Type
- ELECTRIC FUSE
- Rated Current
- 0.75A
- Voltage Rated Ac
- 63V
- Body Height
- 0.97mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Tape & Reel (TR)
- Montaj Tipi
- Surface Mount
- Physical Dimension
- 3.2mm x 1.6mm x 0.97mm
- Boyut / Ölçü
- 0.126Lx0.063W x 0.033 H 3.20mmx1.60mmx0.85mm
- Yüzey Montaj
- YES
- Fuse Type
- Board Mount (Cartridge Style Excluded)
- Body Breadth
- 1.6 mm
- Dc Cold Resistance
- 0.513Ohm
- Temel Parça No
- SF-1206
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- 1206 (3216 Metric)
- Seri
- SinglFuse™ SF-1206SxxxM
- Body Length Or Diameter
- 3.2mm
