Volume pricing
- 1+ pcs$0.68
- 10+ pcs$0.64
- 100+ pcs$0.60
- 500+ pcs$0.57
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reference Standard
- UL
- Melting I2t
- 0.1
- Yüzey Montaj
- YES
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 10 Weeks
- Packing Method
- TR, PAPER, 7 INCH
- Boyut / Ölçü
- 0.063Lx0.031W x 0.037 H 1.60mmx0.80mmx0.95mm
- Breaking Capacity Rated Voltage
- 35A
- Response Time
- Slow Blow
- Body Breadth
- 0.8 mm
- Çalışma Sıcaklığı
- -55°C~125°C
- Body Length Or Diameter
- 1.6mm
- Terminal Shape
- WRAPAROUND
- Current Rating Amps
- 2.5A
- Temel Parça No
- SF-0603
- Montaj Tipi
- Surface Mount
- Voltage Rated Dc
- 32V
- Additional Feature
- SINGLFUSE, PRE ARCING TIME: OPEN WITHIN 5 SEC AT 250% RATED CURRENT
- Body Height
- 0.8mm
- Circuit Protection Type
- ELECTRIC FUSE
- Dc Cold Resistance
- 0.032Ohm
- Fuse Type
- Board Mount (Cartridge Style Excluded)
- Rated Current
- 2.5A
- Ambalaj
- Tape & Reel (TR)
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kılıf / Paket
- 0603 (1608 Metric)
- Physical Dimension
- 1.6mm x 0.8mm x 0.8mm
- Seri
- SinglFuse™ SF-0603SxxxM
- Voltage Rated Ac
- 32V
