Specifications
- Terminal
- SMD/SMT
- Kılıf / Paket
- 1210 (3225 Metric), Concave
- Nominal Gerilim
- 30V
- Power Dissipation
- 600mW
- Reach Svhc
- No SVHC
- Onay Kuruluşu
- cURus, TUV
- Boyut / Ölçü
- 0.127Lx0.102W 3.22mmx2.58mm
- JESD-609 Kodu
- e4
- Terminal Placement
- DUAL ENDED
- Max Current Rating
- 10A
- Trip Current
- 150mA
- Temel Parça No
- MF-USMF
- Resistance Initial Ri Min
- 2.8Ohm
- Hold Current
- 50mA
- Ambient Temperature Range High
- 85°C
- Yükseklik
- 1.1mm
- Terminal Shape
- WRAPAROUND
- Current Hold Ih Max
- 50mA
- Montaj Tipi
- Surface Mount
- Seri
- Multifuse®, MF-USMF
- Parça Durumu
- Active
- Contact Plating
- Gold
- Montaj
- PCB, Surface Mount
- Direnç
- 50Ohm
- Terminal Sayısı
- 2
- Time To Trip
- 1.5s
- Thermistor Application
- OVERLOAD PROTECTION
- Çalışma Sıcaklığı
- -40°C~85°C
- Ratings
- AEC-Q200
- Operating Supply Voltage
- 30V
- Packing Method
- TR, 7 INCH
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Dc
- 30V
- Resistance Post Trip R1 Max
- 50Ohm
- Radyasyon Dayanımı
- No
- Yayın Yılı
- 2006
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 12 Weeks
- Maks. Kalınlık
- 0.033 0.85mm
- Akım Değeri
- 10A
