Specifications
- Temel Parça No
- MF-SM
- Resistance Initial Ri Min
- 60mOhm
- Hold Current
- 1.5A
- Pin Sayısı
- 2
- Yükseklik
- 3mm
- Terminal Shape
- FLAT
- Terminal Kaplaması
- Matte Tin (Sn) - with Nickel (Ni) barrier
- Montaj Tipi
- Surface Mount
- Seri
- Multifuse®, MF-SM
- Terminal Placement
- DUAL ENDED
- Max Current Rating
- 100A
- Trip Current
- 3A
- JESD-609 Kodu
- e3
- Terminal Material
- Brass
- Lead Length
- 430μm
- Kılıf / Paket
- 2-SMD
- Terminal
- SMD/SMT
- Power Dissipation
- 1.9W
- Nominal Gerilim
- 15V
- Onay Kuruluşu
- cURus, TUV
- Reach Svhc
- No SVHC
- Boyut / Ölçü
- 0.344Lx0.264W 8.75mmx6.71mm
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 7 Weeks
- Yayın Yılı
- 2010
- Maks. Kalınlık
- 0.118 3.00mm
- Akım Değeri
- 1.5A
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz
- Lead Free
- RoHS Durumu
- ROHS3 Compliant
- Tip
- Polymeric
- Radyasyon Dayanımı
- No
- Resistance Post Trip R1 Max
- 250mOhm
- Ratings
- AEC-Q200
- Operating Supply Voltage
- 15V
- Voltage Rated Dc
- 15V
- Packing Method
- TR, 14 INCH
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Direnç
- 250mOhm
