Specifications
- Seri
- Multifuse®, MF-SM
- Montaj Tipi
- Surface Mount
- Terminal Shape
- FLAT
- Yükseklik
- 3.18mm
- Hold Current
- 500mA
- Pin Sayısı
- 2
- Resistance Initial Ri Min
- 350mOhm
- Temel Parça No
- MF-SM
- Trip Current
- 1A
- Max Current Rating
- 40A
- Terminal Placement
- DUAL ENDED
- Lead Length
- 430μm
- Terminal Material
- Brass
- JESD-609 Kodu
- e3
- Boyut / Ölçü
- 0.287Lx0.214W 7.31mmx5.44mm
- Reach Svhc
- No SVHC
- Onay Kuruluşu
- cURus, TUV
- Nominal Gerilim
- 60V
- Power Dissipation
- 1.7W
- Terminal
- SMD/SMT
- Kılıf / Paket
- 2-SMD
- Tip
- Polymeric
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Ambalaj
- Tape & Reel (TR)
- Akım Değeri
- 500mA
- Maks. Kalınlık
- 0.125 3.18mm
- Yayın Yılı
- 2004
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 7 Weeks
- Max Power Dissipation
- 1.7W
- Resistance Post Trip R1 Max
- 1.4Ohm
- Voltage Rated Dc
- 60V
- Packing Method
- TR, 14 INCH
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ratings
- AEC-Q200
- Operating Supply Voltage
- 60V
- Çalışma Sıcaklığı
- -40°C~85°C
- Thermistor Application
- OVERLOAD PROTECTION
- Time To Trip
- 4s
