Specifications
- Lead Diameter
- 810 μm
- Ambalaj
- Bulk
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2005
- Time To Trip
- 24s
- Terminal Sayısı
- 2
- Thermistor Application
- OVERLOAD PROTECTION
- Parça Durumu
- Active
- Direnç
- 50mOhm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Material
- Polymer
- Operating Supply Voltage
- 72V
- Trip Current
- 7.5A
- Voltage Rated Ac
- 60V
- Current Hold Ih Max
- 3.75A
- Seri
- Multifuse®, MF-RX/72
- Montaj Tipi
- Through Hole
- Resistance Initial Ri Min
- 30mOhm
- Hold Current
- 3.75A
- Lead Spacing
- 0.402 10.20mm
- Onay Kuruluşu
- cURus, TUV
- Lead Pitch
- 10.2mm
- Terminal
- Radial
- Power Dissipation
- 3.2W
- Thickness
- 3.1mm
- Resistance Post Trip R1 Max
- 80mOhm
- Radyasyon Dayanımı
- No
- Tip
- Polymeric
- Terminal Adımı
- 10.2mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 40A
- Çalışma Sıcaklığı
- -40°C~85°C
- Maks. Oturma Yüksekliği
- 1.161 29.50mm
- Contact Plating
- Tin
- Montaj
- PCB, Through Hole
- Voltage Rated Dc
- 72V
- Flammability Rating
- UL94 V-0
- Max Current Rating
- 40A
