Volume pricing
- 1+ pcs$0.46
- 10+ pcs$0.44
- 100+ pcs$0.41
- 500+ pcs$0.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- JESD-609 Kodu
- e3
- Voltage Rated Dc
- 240V
- Boyut / Ölçü
- 0.551Lx0.161W 14.00mmx4.10mm
- Hold Current
- 550mA
- Akım Değeri
- 7A
- Kılıf / Paket
- Radial, Disc
- Max Power Dissipation
- 3.4W
- Trip Current
- 1.25A
- Reach Svhc
- No SVHC
- Montaj Tipi
- Through Hole
- Seri
- Multifuse®, MF-RM
- Time To Trip
- 26s
- Terminal Kaplaması
- Tin (Sn)
- Lead Pitch
- 5.1mm
- Çalışma Sıcaklığı
- -20°C~85°C
- Ambalaj
- Cut Tape (CT)
- Terminal Sayısı
- 2
- Direnç
- 450mOhm
- Terminal
- Radial
- HTS Kodu
- 8533.40.80.70
- Tip
- Polymeric
- Onay Kuruluşu
- cURus, TUV
- Wirecable Diameter
- 810 μm
- Resistance Initial Ri Min
- 450mOhm
- Montaj
- PCB, Through Hole
- Voltage Max
- 240V 265V Int
- Max Voltage Rating Ac
- 240V
- Lead Spacing
- 0.114 2.90mm
- Maks. Oturma Yüksekliği
- 0.882 22.40mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Operating Supply Voltage
- 240V
- Çap
- 14mm
- Voltage Rated Ac
- 240V
- Lead Diameter
- 810 μm
- Resistance Post Trip R1 Max
- 1.45Ohm
- Yükseklik
- 4.1mm
- Fabrika Tedarik Süresi
- 12 Weeks
- Max Current Rating
- 7A
- ECCN Kodu
- EAR99
