Volume pricing
- 1+ pcs$0.49
- 10+ pcs$0.46
- 100+ pcs$0.43
- 500+ pcs$0.41
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Kaplaması
- Tin (Sn)
- Lead Pitch
- 5.1mm
- Çalışma Sıcaklığı
- -20°C~85°C
- Terminal Sayısı
- 2
- Direnç
- 600mOhm
- Terminal
- Radial
- HTS Kodu
- 8533.40.80.70
- Ambalaj
- Cut Tape (CT)
- Tip
- Polymeric
- Onay Kuruluşu
- cURus, TUV
- Wirecable Diameter
- 650 μm
- Resistance Initial Ri Min
- 600mOhm
- Max Voltage Rating Ac
- 240V
- Lead Spacing
- 0.114 2.90mm
- Montaj
- Through Hole
- Voltage Max
- 240V 265V Int
- JESD-609 Kodu
- e3
- Boyut / Ölçü
- 0.453Lx0.150W 11.50mmx3.80mm
- Voltage Rated Dc
- 240V
- Max Power Dissipation
- 2W
- Kılıf / Paket
- Radial, Disc
- Akım Değeri
- 400mA
- Hold Current
- 400mA
- Seri
- Multifuse®, MF-RM
- Time To Trip
- 24s
- Reach Svhc
- No SVHC
- Trip Current
- 900mA
- Montaj Tipi
- Through Hole
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 9 Weeks
- Max Current Rating
- 5.5A
- Radyasyon Dayanımı
- No
- Temel Parça No
- MF-RM
- Power Dissipation
- 2W
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2012
- Operating Supply Voltage
- 240V
- Maks. Oturma Yüksekliği
- 0.823 20.90mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Discontinued
