Volume pricing
- 1+ pcs$0.52
- 10+ pcs$0.49
- 100+ pcs$0.47
- 500+ pcs$0.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 240V
- Boyut / Ölçü
- 0.449Lx0.150W 11.40mmx3.80mm
- JESD-609 Kodu
- e3
- Montaj Tipi
- Through Hole
- Reach Svhc
- No SVHC
- Trip Current
- 740mA
- Time To Trip
- 21s
- Seri
- Multifuse®, MF-RM
- Akım Değeri
- 330mA
- Hold Current
- 330mA
- Kılıf / Paket
- Radial, Disc
- Max Power Dissipation
- 1.7W
- Ambalaj
- Cut Tape (CT)
- Terminal Sayısı
- 2
- Direnç
- 770mOhm
- Terminal
- Radial
- HTS Kodu
- 8533.40.80.70
- Çalışma Sıcaklığı
- -20°C~85°C
- Lead Pitch
- 5.1mm
- Terminal Kaplaması
- Tin (Sn)
- Voltage Max
- 240V 265V Int
- Montaj
- Through Hole
- Max Voltage Rating Ac
- 240V
- Lead Spacing
- 0.114 2.90mm
- Resistance Initial Ri Min
- 770mOhm
- Wirecable Diameter
- 650 μm
- Onay Kuruluşu
- cURus, TUV
- Tip
- Polymeric
- Çap
- 11.4mm
- Voltage Rated Ac
- 240V
- Lead Diameter
- 650 μm
- Parça Durumu
- Active
- Maks. Oturma Yüksekliği
- 0.787 20.00mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Supply Voltage
- 240V
- Yükseklik
- 3.8mm
- Resistance Post Trip R1 Max
- 2.6Ohm
- Radyasyon Dayanımı
- No
- Fabrika Tedarik Süresi
- 12 Weeks
- Max Current Rating
- 4.5A
