Specifications
- Çalışma Sıcaklığı
- -40°C~85°C
- Fabrika Tedarik Süresi
- 5 Weeks
- Lead Pitch
- 5.1mm
- Seri
- Multifuse®, MF-R
- Radyasyon Dayanımı
- No
- Packing Method
- TR
- Kılıf / Paket
- Radial, Disc
- Akım Değeri
- 40A
- JESD-609 Kodu
- e3
- Trip Current
- 6A
- Current Hold Ih Max
- 3A
- Rated Ac Voltage Urac
- 30V
- Time To Trip
- 10.8s
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Direnç
- 50mOhm
- Montaj Tipi
- Through Hole
- Power Dissipation
- 2W
- Resistance Post Trip R1 Max
- 80mOhm
- Voltage Max
- 30V
- Montaj
- Through Hole
- Parça Durumu
- Obsolete
- Tip
- Polymeric
- Lead Spacing
- 0.201 5.10mm
- Terminal Shape
- WIRE
- Thermistor Application
- TEMPERATURE SENSING
- Terminal Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Terminal
- Radial
- Ambalaj
- Tape & Reel (TR)
- Onay Kuruluşu
- cURus, TUV
- Max Current Rating
- 40A
- Boyut / Ölçü
- 0.472Lx0.118W 12.00mmx3.00mm
- Yayın Yılı
- 2011
- Resistance Initial Ri Min
- 20mOhm
- Temel Parça No
- MF-R300
- Lead Diameter
- 810 μm
- Hold Current
- 3A
- Maks. Oturma Yüksekliği
- 0.720 18.30mm
- Terminal Kaplaması
- Tin (Sn)
