Specifications
- Seri
- Multifuse®, MF-R
- Kılıf / Paket
- Radial, Disc
- Packing Method
- TR
- Fabrika Tedarik Süresi
- 4 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
- Lead Pitch
- 5.1mm
- Rated Ac Voltage Urac
- 30V
- Akım Değeri
- 40A
- Current Hold Ih Max
- 1.35A
- Trip Current
- 2.7A
- JESD-609 Kodu
- e3
- Power Dissipation
- 800mW
- Terminal Adımı
- 5.1mm
- Montaj Tipi
- Through Hole
- Time To Trip
- 7.3s
- RoHS Durumu
- ROHS3 Compliant
- Direnç
- 115mOhm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Obsolete
- Resistance Post Trip R1 Max
- 170mOhm
- Montaj
- Through Hole
- Voltage Max
- 30V
- Contact Plating
- Tin
- Terminal Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Terminal
- Radial
- Tip
- Polymeric
- Terminal Shape
- WIRE
- Lead Spacing
- 0.201 5.10mm
- Thermistor Application
- TEMPERATURE SENSING
- Max Current Rating
- 40A
- Onay Kuruluşu
- cURus, TUV
- Ambalaj
- Tape & Reel (TR)
- Resistance Initial Ri Min
- 65mOhm
- Boyut / Ölçü
- 0.350Dia x 0.118 T 8.90mmx3.00mm
- Yayın Yılı
- 2011
- Maks. Oturma Yüksekliği
- 0.744 18.90mm
- Temel Parça No
- MF-R135
- Hold Current
- 1.35A
- Lead Diameter
- 510 μm
