Specifications
- Akım Değeri
- 40A
- Trip Current
- 1.8A
- JESD-609 Kodu
- e3
- Current Hold Ih Max
- 900mA
- Seri
- Multifuse®, MF-R
- Kılıf / Paket
- Radial, Disc
- Çalışma Sıcaklığı
- -40°C~85°C
- Fabrika Tedarik Süresi
- 4 Weeks
- Lead Length
- 7.6mm
- Reach Svhc
- No SVHC
- Lead Pitch
- 5.1mm
- Parça Durumu
- Obsolete
- Resistance Post Trip R1 Max
- 470mOhm
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole
- Power Dissipation
- 1W
- Voltage Rated Dc
- 60V
- Time To Trip
- 7.2s
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Direnç
- 120mOhm
- Onay Kuruluşu
- cURus, TUV
- Max Current Rating
- 40A
- Ambalaj
- Bulk
- Terminal Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Terminal
- Radial
- Terminal Shape
- WIRE
- Lead Spacing
- 0.201 5.10mm
- Tip
- Polymeric
- Thermistor Application
- TEMPERATURE SENSING
- Terminal Kaplaması
- Matte Tin (Sn)
- Maks. Oturma Yüksekliği
- 0.480 12.20mm
- Operating Supply Voltage
- 60V
- Temel Parça No
- MF-R090
- Lead Diameter
- 510 μm
- Hold Current
- 900mA
- Voltage Rated Ac
- 60V
- Flammability Rating
- UL94 V-0
- Resistance Initial Ri Min
- 140mOhm
