Specifications
- Onay Kuruluşu
- cURus, TUV
- Max Current Rating
- 40A
- Ambalaj
- Bulk
- Contact Plating
- Tin
- Terminal Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Terminal
- Radial
- Terminal Shape
- WIRE
- Lead Spacing
- 0.201 5.10mm
- Tip
- Polymeric
- Thermistor Application
- TEMPERATURE SENSING
- Maks. Oturma Yüksekliği
- 0.630 16.00mm
- Operating Supply Voltage
- 60V
- Temel Parça No
- MF-R075
- Lead Diameter
- 510 μm
- Hold Current
- 750mA
- Voltage Rated Ac
- 60V
- Resistance Initial Ri Min
- 180mOhm
- Flammability Rating
- UL94 V-0
- Boyut / Ölçü
- 0.409Dia x 0.122 T 10.40mmx3.10mm
- Yayın Yılı
- 2011
- Akım Değeri
- 40A
- Trip Current
- 1.5A
- JESD-609 Kodu
- e3
- Current Hold Ih Max
- 750mA
- Seri
- Multifuse®, MF-R
- Radyasyon Dayanımı
- No
- Kılıf / Paket
- Radial, Disc
- Çalışma Sıcaklığı
- -40°C~85°C
- Fabrika Tedarik Süresi
- 4 Weeks
- Lead Length
- 7.6mm
- Lead Pitch
- 5.1mm
- Parça Durumu
- Obsolete
- Resistance Post Trip R1 Max
- 600mOhm
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole
- Power Dissipation
- 900mW
- Terminal Adımı
- 5.1mm
- Voltage Rated Dc
- 60V
- Time To Trip
- 6.3s
