Specifications
- Lead Diameter
- 510 μm
- Hold Current
- 500mA
- Pin Sayısı
- 2
- Nominal Gerilim
- 60V
- Thermistor Application
- TEMPERATURE SENSING
- Tip
- Polymeric
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 2
- Çap
- 7.9mm
- Montaj
- PCB, Through Hole
- Resistance Post Trip R1 Max
- 1.17Ohm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Direnç
- 770mOhm
- Time To Trip
- 4s
- Montaj Tipi
- Through Hole
- Trip Current
- 1A
- JESD-609 Kodu
- e3
- Ambient Temperature Range High
- 85°C
- Lead Length
- 7.6mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Kılıf / Paket
- Radial, Disc
- Seri
- Multifuse®, MF-R
- Operating Supply Voltage
- 60V
- Maks. Oturma Yüksekliği
- 0.539 13.70mm
- Yayın Yılı
- 2006
- Boyut / Ölçü
- 0.311Dia x 0.122 T 7.90mmx3.10mm
- Resistance Initial Ri Min
- 410mOhm
- Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- Max Power Dissipation
- 750mW
- Ambalaj
- Bulk
- Onay Kuruluşu
- cURus, TUV
- Max Current Rating
- 40A
- Terminal Shape
- WIRE
- Lead Spacing
- 0.201 5.10mm
- Terminal
- Radial
- Contact Plating
- Tin
- Parça Durumu
- Active
- Yükseklik
- 13.7mm
- RoHS Durumu
- ROHS3 Compliant
