Specifications
- Yayın Yılı
- 2011
- Boyut / Ölçü
- 0.291Dia x 0.122 T 7.40mmx3.10mm
- Resistance Initial Ri Min
- 760mOhm
- Hold Current
- 300mA
- Lead Diameter
- 510 μm
- Temel Parça No
- MF-R030
- Operating Supply Voltage
- 60V
- Terminal Kaplaması
- Tin (Sn)
- ECCN Kodu
- EAR99
- Maks. Oturma Yüksekliği
- 0.528 13.40mm
- Thermistor Application
- TEMPERATURE SENSING
- Tip
- Polymeric
- Lead Spacing
- 0.201 5.10mm
- Terminal Shape
- WIRE
- Terminal Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Terminal
- Radial
- Ambalaj
- Tape & Box (TB)
- Max Current Rating
- 40A
- Onay Kuruluşu
- cURus, TUV
- RoHS Durumu
- ROHS3 Compliant
- Direnç
- 1.36Ohm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Time To Trip
- 3s
- Voltage Rated Dc
- 60V
- HTS Kodu
- 8533.40.80.70
- Power Dissipation
- 500mW
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Resistance Post Trip R1 Max
- 2.1Ohm
- Parça Durumu
- Active
- Lead Pitch
- 5.1mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
- Packing Method
- AMMO PACK
- Kılıf / Paket
- Radial, Disc
- Radyasyon Dayanımı
- No
- Seri
- Multifuse®, MF-R
- Current Hold Ih Max
- 300mA
- JESD-609 Kodu
- e3
