Specifications
- Radyasyon Dayanımı
- No
- Kılıf / Paket
- Radial, Box
- Seri
- Multifuse®, MF-R/600
- Çalışma Sıcaklığı
- -40°C~85°C
- Fabrika Tedarik Süresi
- 15 Weeks
- Rated Ac Voltage Urac
- 60V
- JESD-609 Kodu
- e3
- Trip Current
- 320mA
- Yüzey Montaj
- NO
- Additional Feature
- 4 OHMS MINIMUM AT 23 DEG CEL
- Montaj Tipi
- Through Hole
- Power Dissipation
- 1W
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Time To Trip
- 7s
- Parça Durumu
- Obsolete
- Voltage Max
- 250V 600V Int
- Resistance Post Trip R1 Max
- 16Ohm
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 2
- Thermistor Application
- TEMPERATURE SENSING
- Tip
- Polymeric
- Lead Spacing
- 0.197 5.00mm
- Terminal Shape
- WIRE
- Onay Kuruluşu
- cURus, TUV
- Max Current Rating
- 3A
- Ambalaj
- Bag
- Resistance Initial Ri Min
- 4Ohm
- Yayın Yılı
- 2005
- Boyut / Ölçü
- 0.630Lx0.236W 16.00mmx6.00mm
- Maks. Oturma Yüksekliği
- 0.496 12.60mm
- Terminal Kaplaması
- Tin (Sn)
- Hold Current
- 160mA
- Temel Parça No
- MF-R016
