Specifications
- Power Dissipation
- 220mW
- Montaj Tipi
- Through Hole
- Direnç
- 11.1Ohm
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Time To Trip
- 5s
- Parça Durumu
- Obsolete
- Montaj
- Through Hole
- Voltage Max
- 60V
- Resistance Post Trip R1 Max
- 22Ohm
- Packing Method
- AMMO PACK
- Kılıf / Paket
- Radial, Disc
- Seri
- Multifuse®, MF-R
- Lead Pitch
- 5.1mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
- Rated Ac Voltage Urac
- 60V
- Current Hold Ih Max
- 50mA
- Trip Current
- 100mA
- JESD-609 Kodu
- e3
- Akım Değeri
- 40A
- Resistance Initial Ri Min
- 7.3Ohm
- Yayın Yılı
- 2011
- Boyut / Ölçü
- 0.315Dia x 0.122 T 8.00mmx3.10mm
- Maks. Oturma Yüksekliği
- 0.327 8.30mm
- Terminal Kaplaması
- Tin (Sn)
- Hold Current
- 50mA
- Lead Diameter
- 400 μm
- Temel Parça No
- MF-R005
- Terminal Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Terminal
- Radial
- Thermistor Application
- TEMPERATURE SENSING
- Tip
- Polymeric
- Lead Spacing
- 0.201 5.10mm
- Terminal Shape
- WIRE
- Max Current Rating
- 40A
- Onay Kuruluşu
- cURus, TUV
- Ambalaj
- Tape & Box (TB)
