Specifications
- Kurşunsuz
- Contains Lead
- Seri
- Multifuse®, MF-MSMD
- Çalışma Sıcaklığı
- -40°C~85°C
- Trip Current
- 1A
- Parça Durumu
- Obsolete
- Yayın Yılı
- 2004
- Packing Method
- TR
- Tip
- Polymeric
- Ambalaj
- Tape & Reel (TR)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Power Dissipation
- 1.2W
- Terminal Sayısı
- 2
- Case Code Metric
- 4532
- Operating Supply Voltage
- 15V
- Hold Current
- 500mA
- Akım Değeri
- 500mA
- Voltage Max
- 15V
- Kılıf / Paket
- 1812 (4532 Metric)
- Boyut / Ölçü
- 0.179Lx0.020W 4.55mmx0.50mm
- RoHS Durumu
- Non-RoHS Compliant
- Onay Kuruluşu
- CSA, TUV, UR
- HTS Kodu
- 8533.40.80.70
- Time To Trip
- 150ms
- Temel Parça No
- MF-MSMD
- Resistance Initial Ri Min
- 150mOhm
- Max Current Rating
- 100A
- Additional Feature
- 0.15 OHMS MINIMUM AT 23 DEG CEL
- Maks. Kalınlık
- 0.134 3.41mm
- Resistance Post Trip R1 Max
- 1Ohm
- Montaj Tipi
- Surface Mount
- Yükseklik
- 620μm
- Terminal Placement
- DUAL
- Terminal Shape
- WRAPAROUND
- Reach Svhc
- No SVHC
- Terminal
- SMD/SMT
- Thermistor Application
- TEMPERATURE SENSING
- Voltage Rated Dc
- 15V
- Yüzey Montaj
- YES
- ECCN Kodu
- EAR99
- Case Code Imperial
- 1812
