Specifications
- RoHS Durumu
- ROHS3 Compliant
- Boyut / Ölçü
- 0.984Lx0.604W 25.00mmx15.35mm
- Kılıf / Paket
- Strap
- Akım Değeri
- 100A
- JESD-609 Kodu
- e2
- Terminal Sayısı
- 2
- Hold Current
- 3.4A
- Operating Supply Voltage
- 24V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Power Dissipation
- 2.7W
- Yayın Yılı
- 2011
- Tip
- Polymeric
- Mounting Feature
- SURFACE MOUNT
- Trip Current
- 6.8A
- Çalışma Sıcaklığı
- -40°C~85°C
- Seri
- Multifuse®, MF-LS
- Parça Durumu
- Obsolete
- Current Hold Ih Max
- 3.4A
- Direnç
- 27mOhm
- Voltage Rated Dc
- 24V
- Thermistor Application
- OVERLOAD PROTECTION
- Terminal
- Axial
- ECCN Kodu
- EAR99
- Yüzey Montaj
- YES
- Terminal Shape
- FLAT
- Radyasyon Dayanımı
- No
- Terminal Placement
- DUAL
- Montaj Tipi
- User Defined
- Terminal Kaplaması
- Tin/Silver (Sn/Ag)
- Maks. Kalınlık
- 0.039 1.00mm
- Resistance Post Trip R1 Max
- 50mOhm
- Max Current Rating
- 100A
- Additional Feature
- 0.016 OHMS MINIMUM AT 23 DEG CEL
- Temel Parça No
- MF-LS
- Resistance Initial Ri Min
- 16mOhm
- Onay Kuruluşu
- cURus, TUV
- HTS Kodu
- 8533.40.80.70
- Time To Trip
- 5s
