Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Thermistor Application
- OVERLOAD PROTECTION
- Terminal
- Axial
- Voltage Rated Dc
- 20V
- Direnç
- 12mOhm
- Reach Svhc
- No SVHC
- Radyasyon Dayanımı
- No
- Terminal Shape
- FLAT
- Resistance Post Trip R1 Max
- 15mOhm
- Fabrika Tedarik Süresi
- 12 Weeks
- Maks. Kalınlık
- 0.039 1.00mm
- Terminal Kaplaması
- Tin/Silver (Sn/Ag)
- Montaj Tipi
- User Defined
- Yükseklik
- 1mm
- Terminal Material
- Nickel
- Montaj
- Surface Mount
- HTS Kodu
- 8533.40.80.70
- Onay Kuruluşu
- cURus, TUV
- Time To Trip
- 5s
- Resistance Initial Ri Min
- 6mOhm
- Temel Parça No
- MF-LR
- Additional Feature
- 0.006 TO 0.012 OHMS AT 23 DEG CEL
- Max Current Rating
- 100A
- Kılıf / Paket
- Strap
- Boyut / Ölçü
- 1.106Lx0.559W 28.10mmx14.20mm
- RoHS Durumu
- ROHS3 Compliant
- Operating Supply Voltage
- 20V
- Hold Current
- 7.3A
- Terminal Sayısı
- 2
- JESD-609 Kodu
- e2
- Akım Değeri
- 100A
- Tip
- Polymeric
- Yayın Yılı
- 2005
- Power Dissipation
- 3W
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Hold Ih Max
- 7.3A
- Parça Durumu
- Active
- Seri
- Multifuse®, MF-LR
- Nominal Gerilim
- 20V
