Specifications
- JESD-609 Kodu
- e3
- Pin Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dc Cold Resistance
- 0.35Ohm
- Tip
- Electrical
- Onay Kuruluşu
- UR
- Fuse Type
- Board Mount
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Plating
- Tin
- Max Power Dissipation
- 200mW
- Direnç
- 350mOhm
- Terminal
- SMD/SMT
- Depth
- 3.05mm
- Kurşunsuz
- Lead Free
- Montaj
- Surface Mount
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- 2-SMD, Square End Block
- HTS Kodu
- 8536.10.00.40
- Melting I2t
- 2.3
- Body Material
- Ceramic
- Reference Standard
- UL
- Max Voltage Rating Ac
- 600V
- Voltage Rated Ac
- 600V
- Body Length Or Diameter
- 9.65mm
- Terminal Shape
- END CAP
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2009
- Power Dissipation
- 200mW
- Boyut / Ölçü
- 0.380Lx0.120W x 0.120 H 9.65mmx3.05mmx3.05mm
- Akım
- 500mA
- Applications
- Telecom
- Yükseklik
- 3.177mm
- Fuse Current
- 500mA
- Seri
- Telefuse™
- Parça Durumu
- Obsolete
- Fabrika Tedarik Süresi
- 18 Weeks
- Joule Integralnom
- 2 J
- Radyasyon Dayanımı
- No
- Physical Dimension
- 9.65mm x 3.05mm x 3.05mm
