Specifications
- Max Voltage Rating Dc
- 30V
- Dielectric Withstanding Voltage
- 500VAC V
- Orientation
- Straight
- Housing Material
- Thermoplastic
- Uzunluk
- 15.7mm
- Voltage Rated Dc
- 30V
- Durability
- 5000 Cycles
- Yayın Yılı
- 2011
- Pitch
- 0.157 4.00mm
- Bodyshell Style
- RECEPTACLE
- Seri
- 70AD
- Option
- GENERAL PURPOSE
- Ambalaj
- Tube
- Iec Conformance
- NO
- Flammability Rating
- UL94 V-0
- Reference Standard
- UL
- Rated Current Signal
- 3A
- Connector Type
- Compression Contact, Male
- Depth
- 11mm
- Yükseklik
- 5.65mm
- Maks. Çalışma Sıcaklığı
- 125°C
- Contact Resistance
- 25mOhm
- Din Conformance
- NO
- Radyasyon Dayanımı
- No
- RoHS Durumu
- ROHS3 Compliant
- Number Of Conductors
- ONE
- Material
- Copper Alloy
- Gender
- Male
- Renk
- Black
- Montaj
- Surface Mount
- Kurşunsuz
- Lead Free
- Terminal
- Solder
- Plating Thickness
- 30μin
- Number Of Pcb Rows
- 2
- Fabrika Tedarik Süresi
- 8 Weeks
- Kurşunsuz Kodu
- yes
- Pcb Contact Row Spacing
- 9.525 mm
- Parça Durumu
- Active
- Mil Conformance
- NO
- Contact Finish Thickness
- 30.0μin 0.76μm
