Specifications
- Uzunluk
- 500.0' 152.40m
- Connector Support Type
- WIRE AND CABLE
- Fabrika Tedarik Süresi
- 10 Weeks
- Cable Types
- Twinaxial - Plenum
- Empedans
- 78Ohm
- Conductor Strand
- 7 Strands / 28 AWG
- Wire Gauge
- 20 AWG
- Shield Material
- Aluminum; Copper, Tinned
- Dielectric Material
- Polyethylene (PE)
- Vop Velocity Of Propagation
- 66
- Insulation Materials
- PE
- Stranding
- 7X28
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Conductors
- 2
- Rated Voltage
- 300V
- Construction
- STRANDED
- Direnç
- 0.031Ohm
- Onay Kuruluşu
- CE; CEC; CUL; NEC; UL
- Çalışma Sıcaklığı
- -40°C~80°C
- Parça Durumu
- Active
- Jacket Insulation Material
- Poly-Vinyl Chloride (PVC)
- Shielding
- YES
- Seri
- Blue Hose®
- Dielectric Diameter
- 0.078 (1.98mm)
- Yayın Yılı
- 2008
- Wire And Cable Name
- COMMUNICATION CABLE
- Shield Type
- Foil, Braid
- Shield Coverage
- 100%, 55%
- Conductor Material
- Copper, Tinned
- Jacket Color
- Blue
- Jacket Insulation Diameter
- 0.238 (6.05mm)
- RoHS Durumu
- ROHS3 Compliant
