Specifications
- Pozisyon Sayısı
- 132 (110 + 22 Ground)
- Ul Flammability Code
- 94V-0
- Mil Conformance
- NO
- Filter Feature
- NO
- Ambalaj
- Bulk
- Contact Pattern
- RECTANGULAR
- Option
- GENERAL PURPOSE
- Seri
- 7200
- Additional Feature
- PICMG, STANDARD: IEC 61076-4-101, 22 GROUND SHIELD CONTACTS IN 1 ROW ALSO AVAILABLE
- Contact Finish Thickness
- 31.5μin 0.80μm
- REACH Uyumluluk Kodu
- compliant
- Current Rating Amps
- 1A
- Reliability
- COMMERCIAL
- Number Of Conductors
- ONE
- Contact Resistance
- 20mOhm
- Mixed Contacts
- NO
- Connector Style
- B 22
- Body Length Or Diameter
- 1.728 inch
- Iec Conformance
- YES
- Dielectric Withstanding Voltage
- 750VAC V
- ECCN Kodu
- EAR99
- Terminal
- Press-Fit
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mating Contact Row Spacing
- 0.079 inch
- Çalışma Sıcaklığı
- -55°C~125°C
- Özellikler
- Upper Shield
- Contact Style
- SQ PIN-SKT
- Sıra Sayısı
- 5 + 1
- Plating Thickness
- 31μin
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Total Number Of Contacts
- 110
- Reference Standard
- UL
- Montaj Tipi
- Through Hole, Right Angle
- Yayın Yılı
- 2005
- RoHS Durumu
- RoHS Compliant
- Durability
- 250 Cycles
- Connector Type
- Receptacle, Female Sockets
- Withdrawl Forcemin
- .139 N
- Pcb Contact Pattern
- RECTANGULAR
- Din Conformance
- NO
