Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Discontinued
- Ambalaj
- Bulk
- Terminal Kaplaması
- Gold (Au)
- Montaj Tipi
- Chassis Mount
- Dc Resistance Dcr
- 10mOhm
- Fabrika Tedarik Süresi
- 10 Weeks
- Depth
- 12.7mm
- ECCN Kodu
- EAR99
- Resistance Channel
- 0.01
- Boyut / Ölçü
- 0.500Diax0.500L 12.70mmx12.70mm
- Max Voltage Rating Dc
- 2.5kV
- Kılıf / Paket
- Axial, Bushing - 2 Notched Leads
- Number Of Channels
- 1
- Voltage Rated Dc
- 2.5kV
- Circuit Type
- Filter
- Fonksiyon Sayısı
- 1
- Applications
- General Purpose
- Additional Feature
- C-TYPE CIRCUIT
- Max Current Rating
- 25A
- Rated Voltage
- 2500V
- RoHS Durumu
- Non-RoHS Compliant
- Filter Order
- 3rd
- JESD-609 Kodu
- e4
- Onay Kuruluşu
- UL; CSA
- Values
- C = 1500pF
- Max Dc Current
- 25A
- Kapasitans
- 1.5nF
- Yayın Yılı
- 2013
- HTS Kodu
- 8504.50.80.00
- Çalışma Sıcaklığı
- -55°C~125°C
- Montaj
- Chassis Mount
- Esd Protection
- No
- Insertion Loss Db
- 50 dB
- Attenuation Value
- 50dB @ 100MHz ~ 10GHz
- Reach Svhc
- No SVHC
- Akım Değeri
- 25A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tip
- Low Pass
