Specifications
- Lens Transparency
- Diffused
- Terminal
- Wire Leads
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 2
- Tip
- LED
- Nominal Gerilim
- 2V
- Ratings
- Vf (Typ), If (Max)
- Lens Style
- Round with Flat Top
- Terminal Stili
- Wire Leads - 7.87 (200.00mm)
- Uzunluk
- 15.9mm
- Panel Cutout Dimensions
- 0.24 (6.10mm)
- Lamp Color
- Green
- Seri
- Q Series
- Packing Method
- BULK
- Forward Current
- 20mA
- Fabrika Tedarik Süresi
- 13 Weeks
- Overall Height
- 1mm
- Lens Size
- 3mm T-1
- Fonksiyon Sayısı
- 1
- Millicandela Rating
- 8mcd
- Akım Değeri
- 20mA
- Panel Cutout Shape
- Round
- Configuration
- SINGLE
- HTS Kodu
- 8541.40.20.00
- Additional Feature
- UL RECOGNIZED
- Ingress Protection
- IP67
- Luminous Intensity
- 12 mcd
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Viewing Angle
- 100°
- Montaj
- Panel
