Specifications
- Mounting Feature
- PANEL MOUNT
- Viewing Angle
- 100°
- Maks. Çalışma Sıcaklığı
- 85°C
- Forward Voltage
- 12V
- Parça Durumu
- Active
- Luminous Intensity
- 8 mcd
- Ingress Protection
- IP67
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Min. Çalışma Sıcaklığı
- -40°C
- RoHS Durumu
- ROHS3 Compliant
- Configuration
- SINGLE
- Life Hours
- 100000 hours
- Additional Feature
- UL RECOGNIZED
- HTS Kodu
- 8541.40.20.00
- Material
- Brass
- Yüzey Montaj
- NO
- Akım Değeri
- 20mA
- Panel Cutout Shape
- Round
- Fonksiyon Sayısı
- 1
- Forward Current
- 20mA
- Fabrika Tedarik Süresi
- 13 Weeks
- Overall Height
- 1mm
- Lens Size
- 3mm T-1
- Seri
- Q Series
- Packing Method
- BULK
- Lamp Color
- Yellow
- Panel Cutout Dimensions
- 0.24 (6.10mm)
- Operating Supply Voltage
- 12V
- Uzunluk
- 34mm
- Terminal Stili
- Solder Lug
- Nominal Gerilim
- 12V
- Ratings
- DC
- Lens Style
- Round with Flat Top
- Tip
- LED
- Lens Transparency
- Diffused
- Terminal
- Solder
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 2
