Specifications
- Illumination Color
- Green, Red, Yellow
- Terminal Sayısı
- 3
- Forward Current
- 20mA
- Panel Cutout Dimensions
- 0.75 (19.05mm)
- Fonksiyon Sayısı
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Lens Color
- White
- HTS Kodu
- 8541.40.20.00
- Parça Durumu
- Active
- Forward Voltage
- 12V
- Operating Temperature Max
- 85°C
- Mounting Feature
- PANEL MOUNT
- Seri
- Q Series
- Yüzey Montaj
- NO
- Akım
- 20mA Green 20mA Red 20mA Yellow
- Panel Cutout Shape
- Round
- Terminal
- Quick Connect
- Ratings
- DC
- Millicandela Rating
- 50mcd Green, 80mcd Red, 50mcd Yellow
- Kurşunsuz Kodu
- yes
- Additional Feature
- UL RECOGNIZED
- Packing Method
- BULK
- Luminous Intensity
- 50 mcd
- Overall Height
- 4.75mm
- Lens Transparency
- Diffused
- Renk
- Green, Red, Yellow
- Tip
- LED
- Kılıf / Paket
- Metal
- Life Hours
- 100000 hours
- Operating Temperature Min
- -40°C
- Lens Style
- Round with Domed Top
- Configuration
- COMMON CATHODE, 2 ELEMENTS
- Ingress Protection
- IP67
- Fabrika Tedarik Süresi
- 13 Weeks
- Lens Size
- 10.00mm Dia
- Lamp Color
- Green, Red, Yellow
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Viewing Angle
- 60°
- RoHS Durumu
- ROHS3 Compliant
- Gerilim
- 12V Green 12V Red 12V Yellow
