Specifications
- Fabrika Tedarik Süresi
- 13 Weeks
- Lamp Color
- Red
- Lens Size
- 10.00mm Dia
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Gerilim
- 110V
- Viewing Angle
- 60°
- RoHS Durumu
- ROHS3 Compliant
- Lens Transparency
- Diffused
- Overall Height
- 4.75mm
- Tip
- LED
- Lens Style
- Round with Domed Top
- Operating Temperature Min
- -40°C
- Life Hours
- 100000 hours
- Kılıf / Paket
- Metal
- Ingress Protection
- IP67
- Configuration
- SINGLE
- Operating Temperature Max
- 85°C
- Mounting Feature
- PANEL MOUNT
- Seri
- Q Series
- Yüzey Montaj
- NO
- Terminal
- Quick Connect
- Ratings
- AC
- Panel Cutout Shape
- Round
- Additional Feature
- UL RECOGNIZED
- Kurşunsuz Kodu
- yes
- Luminous Intensity
- 100 mcd
- Packing Method
- BULK
- Forward Current
- 6mA
- Terminal Sayısı
- 2
- Fonksiyon Sayısı
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Panel Cutout Dimensions
- 0.75 (19.05mm)
- HTS Kodu
- 8541.40.20.00
- Forward Voltage
- 2V
- Parça Durumu
- Active
