Specifications
- Ratings
- DC
- Overall Height
- 4.75mm
- Fabrika Tedarik Süresi
- 13 Weeks
- HTS Kodu
- 8541.40.20.00
- Configuration
- COMMON CATHODE, 2 ELEMENTS
- Parça Durumu
- Active
- Panel Cutout Shape
- Round
- Tip
- LED
- Yüzey Montaj
- NO
- Lamp Color
- Green, Red, Yellow
- Packing Method
- BULK
- Illumination Color
- Green, Red, Yellow
- Gerilim
- 12V Green 12V Red 12V Yellow
- Akım
- 20mA Green 20mA Red 20mA Yellow
- Lens Color
- White
- Ingress Protection
- IP67
- Lens Size
- 10.00mm Dia
- Panel Cutout Dimensions
- 0.55 (13.97mm)
- Forward Voltage
- 12V
- Maks. Çalışma Sıcaklığı
- 85°C
- Renk
- Green, Red, Yellow
- Terminal
- Quick Connect
- Terminal Sayısı
- 3
- Additional Feature
- UL RECOGNIZED
- Life Hours
- 100000 hours
- Luminous Intensity
- 50 mcd
- Viewing Angle
- 100°
- Forward Current
- 20mA
- Terminal Kaplaması
- NOT SPECIFIED
- Millicandela Rating
- 50mcd Green, 80mcd Red, 50mcd Yellow
- Fonksiyon Sayısı
- 1
- Lens Style
- Round with Domed Top
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- No SVHC
- Kurşunsuz Kodu
- yes
- Mounting Feature
- PANEL MOUNT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Min. Çalışma Sıcaklığı
- -40°C
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Seri
- Q Series
