Specifications
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- No SVHC
- Uzunluk
- 30.6mm
- Millicandela Rating
- 30mcd Green, 180mcd Red, 30mcd Yellow
- Terminal Kaplaması
- NOT SPECIFIED
- Lens Style
- Round with Flat Top
- Fonksiyon Sayısı
- 1
- Lens Transparency
- Diffused
- Seri
- Q Series
- Terminal Stili
- Wire Leads - 7.87 (200.00mm)
- Operating Temperature Max
- 85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Temperature Min
- -40°C
- Tip
- LED
- Akım Değeri
- 20mA
- Panel Cutout Shape
- Round
- Packing Method
- BULK
- Lamp Color
- Green, Red, Yellow
- Fabrika Tedarik Süresi
- 13 Weeks
- Overall Height
- 1.5mm
- Ratings
- DC
- HTS Kodu
- 8541.40.20.00
- Configuration
- COMMON CATHODE, 2 ELEMENTS
- Parça Durumu
- Active
- Terminal Sayısı
- 3
- Terminal
- Wire Leads
- Renk
- Green, Red, Yellow
- Additional Feature
- UL RECOGNIZED
- Forward Voltage
- 12V
- Viewing Angle
- 100°
- Luminous Intensity
- 30 mcd
- Montaj
- Flush
- Gerilim
- 12V Green 12V Red 12V Yellow
- Panel Cutout Dimensions
- 0.55 (13.97mm)
- Lens Size
- 10.00mm Dia
- Ingress Protection
- IP67
- Akım
- 20mA Green 20mA Red 20mA Yellow
- Nominal Gerilim
- 12V
