Volume pricing
- 1+ pcs$0.82
- 10+ pcs$0.78
- 100+ pcs$0.73
- 500+ pcs$0.69
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Timing
- Not Specified
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8536.50.90.50
- Ambalaj
- Tube
- Illumination Type
- Non-Illuminated
- Contact Finish
- Silver
- Contact Materials
- Phosphor Bronze
- Orientation
- Straight
- Switch Travel
- 4.90mm
- Çalışma Sıcaklığı
- -20°C~60°C
- Insulation Materials
- PHENOLIC
- Voltage Rated Ac
- 125V
- Operating Force
- 500gf
- Terminal
- Solder
- Additional Feature
- UL & CSA
- Body Length Or Diameter
- 35mm
- Contact Currentacmax
- 6A
- Body Height
- 9mm
- Akım Değeri
- 6A
- Montaj Tipi
- Panel Mount
- Parça Durumu
- Active
- Dielectric Withstanding Voltage
- 1000VAC V
- JESD-609 Kodu
- e3
- Terminal Material
- BRASS
- Body Breadth
- 13.2 mm
- Contact Ac Max Rating R Load
- 6A@125VAC
- Insulation Resistance
- 100000000Ohm
- Housing Material
- STEEL
- Actuator Type
- Standard
- Max Voltage Rating Ac
- 250V
- Circuit
- SPDT
- Switch Function
- On-On
- Seri
- PM
- Pozisyon Sayısı
- 2
- Terminal Kaplaması
- Tin (Sn)
- Montaj
- Panel, Solder
- Actuator Length
- 9.00mm
- Switch Type
- SLIDE SWITCH
- Terminal Stili
- Solder Lug
