Volume pricing
- 1+ pcs$3.43
- 10+ pcs$3.24
- 100+ pcs$3.05
- 500+ pcs$2.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuator Length
- 0m
- Orientation
- Straight
- HTS Kodu
- 8536.50.90.50
- Çalışma Sıcaklığı
- -30°C~90°C
- Voltage Rated Dc
- 24V
- Pitch
- 0.100 2.54mm Full
- Kurşunsuz Kodu
- yes
- Actuator Level
- Flush, Recessed
- Housing Material
- Thermoplastic
- Contact Finish
- Gold
- Body Breadth
- 7.4 mm
- Switching Voltage
- 24V
- Body Height
- 3.85mm
- Insulation Resistance
- 100MOhm
- Number Of Poles
- 1
- Actuator Type
- Rotary for Tool
- Illumination Type
- Illuminated, Non-Illuminated
- Throw Configuration
- SP16T
- Contact Currentdcmax
- 0.4A
- Uzunluk
- 0.291 7.40mm
- Pozisyon Sayısı
- 16
- Contact Resistance
- 100mOhm
- Switch Type
- ROTARY CODED SWITCH
- Terminal Stili
- Gull Wing
- Packing Method
- TAPE AND REEL
- Montaj
- Surface Mount
- Washable
- Yes
- Nominal Gerilim
- 24VDC
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Phosphor Bronze
- Fabrika Tedarik Süresi
- 10 Weeks
- Parça Durumu
- Active
- Contact Current Rating
- 100mA
- Life Cycles
- 10000 cycles
- Mechanical Life
- 10,000 Cycles
- Max Voltage Rating Dc
- 24V
- Height Above Board
- 0.152 3.85mm
- Terminal Adımı
- 2.54mm
- Contact Function
- BINARY CODED
