Volume pricing
- 1+ pcs$2.90
- 10+ pcs$2.74
- 100+ pcs$2.58
- 500+ pcs$2.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Body Breadth
- 6.5 mm
- Pozisyon Sayısı
- 1
- Seri
- NK
- Contact Materials
- Nickel
- Current Rating Amps
- 500mA DC
- Terminal Stili
- PC Pin
- Fabrika Tedarik Süresi
- 5 Weeks
- Actuator Material
- Polyamide (PA66), Nylon 6/6, Glass Filled
- Contact Timing
- Not Specified
- Orientation
- Right Angle
- Parça Durumu
- Active
- Uzunluk
- 10mm
- Circuit
- SPDT
- Max Voltage Rating Dc
- 12V
- Switch Travel
- 1.60mm
- Depth
- 8.9mm
- Switch Type
- SLIDE SWITCH
- Terminal
- PC Pin
- Contact Current Rating
- 500mA
- Akım Değeri
- 500mA
- Electricallife
- 2,000 Cycles
- Insulation Resistance
- 10000000000Ohm
- Pcb Hole Count
- 3
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Through Hole
- HTS Kodu
- 8536.50.90.50
- Contact Resistance
- 20mOhm
- Contact Finish
- Gold
- Ambalaj
- Bulk
- Contact Ac Max Rating R Load
- .5A@12VAC
- Voltage Rated Dc
- 12V
- Body Height
- 2.6mm
- Switch Function
- On-On
- Contact Currentdcmax
- 0.5A
- Flammability Rating
- UL94 V-0
- JESD-609 Kodu
- e4
- Actuator Type
- Standard
- Max Voltage Rating Ac
- 12V
- Contact Dc Max Rating R Load
- .5A@12VDC
- Max Current Rating
- 500mA
