Volume pricing
- 1+ pcs$5.40
- 10+ pcs$5.10
- 100+ pcs$4.81
- 500+ pcs$4.54
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pozisyon Sayısı
- 1
- Contact Resistance
- 20mOhm
- Contact Finish
- Gold
- RoHS Durumu
- ROHS3 Compliant
- Length Termination
- 0.146 inch
- Pcb Hole Count
- 3
- Insulation Resistance
- 10000000000Ohm
- Montaj
- PCB, Through Hole
- HTS Kodu
- 8536.50.90.50
- Body Breadth
- 6.5 mm
- Voltage Rated Dc
- 12V
- Actuator Material
- Polyamide (PA66), Nylon 6/6, Glass Filled
- Contact Ac Max Rating R Load
- .5A@12VAC
- Fabrika Tedarik Süresi
- 5 Weeks
- Contact Currentdcmax
- 0.5A
- Switch Function
- On-On
- Body Height
- 2.6mm
- Contact Materials
- Nickel
- Current Rating Amps
- 500mA DC
- Seri
- NK
- Terminal Stili
- PC Pin
- Ambalaj
- Bulk
- Body Length Or Diameter
- 10mm
- ECCN Kodu
- EAR99
- Contact Dc Max Rating R Load
- .5A@12VDC
- Circuit
- SPDT
- Çalışma Sıcaklığı
- -40°C~85°C
- Contact Timing
- Not Specified
- Actuator Type
- Flush
- Parça Durumu
- Active
- JESD-609 Kodu
- e4
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole, Right Angle
- Akım Değeri
- 500mA
- Contact Currentacmax
- 0.5A
- Electricallife
- 2,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Type
- SLIDE SWITCH
- Switch Travel
- 1.60mm
- Contact Current Rating
- 500mA
