Volume pricing
- 1+ pcs$1.39
- 10+ pcs$1.32
- 100+ pcs$1.24
- 500+ pcs$1.17
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Switch Function
- On-On
- Contact Currentdcmax
- 0.5A
- Voltage Rated Dc
- 12V
- Contact Ac Max Rating R Load
- .5A@12VAC
- HTS Kodu
- 8536.50.90.50
- Montaj
- Through Hole
- Pcb Hole Count
- 3
- Insulation Resistance
- 10GOhm
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish
- Gold
- Contact Resistance
- 20mOhm
- Genişlik
- 2.6mm
- Özellikler
- Sealed - Flux Protection
- Voltage Rated Ac
- 12V
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Through Hole
- Contact Currentacmax
- 0.5A
- JESD-609 Kodu
- e4
- Flammability Rating
- UL94 V-0
- Actuator Type
- Flush
- Çalışma Sıcaklığı
- -40°C~85°C
- Max Current Rating
- 500mA
- Contact Dc Max Rating R Load
- .5A@12VDC
- Max Voltage Rating Ac
- 12V
- ECCN Kodu
- EAR99
- Terminal Stili
- PC Pin
- Seri
- NK
- Contact Materials
- Nickel
- Current Rating Amps
- 500mA DC
- Actuator Material
- Polyamide (PA66), Nylon 6/6, Glass Filled
- Fabrika Tedarik Süresi
- 5 Weeks
- Pozisyon Sayısı
- 3
- Terminal
- PC Pin
- Contact Current Rating
- 500mA
- Switch Travel
- 1.60mm
- Life Cycles
- 2000 cycles
- Yükseklik
- 6.5mm
- Depth
- 2.6mm
