Specifications
- Voltage Rated Ac
- 28V
- Body Length Or Diameter
- 17mm
- Body Breadth
- 6 mm
- Terminal
- PC Pin
- Özellikler
- Epoxy Sealed Terminals
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Through Hole
- Sealing
- EPOXY TERMINAL SEALED
- ECCN Kodu
- EAR99
- Body Height
- 5.2mm
- Circuit
- DP3T
- Parça Durumu
- Obsolete
- Electricallife
- 10,000 Cycles
- Pcb Hole Count
- 10
- Housing Material
- Steel
- Akım Değeri
- 300mA
- Contact Finish
- Silver
- Pozisyon Sayısı
- 3
- Washability
- SOLVENT
- Seri
- MSTS
- Length Termination
- 0.118 inch
- Switch Travel
- 2.50mm
- HTS Kodu
- 8536.50.90.50
- Actuator Type
- Standard
- Insulation Resistance
- 100000000Ohm
- Actuator Material
- Polyacetal
- Max Voltage Rating Dc
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- JESD-609 Kodu
- e4
- Montaj
- Brackets, Through Hole
- Contact Currentdcmax
- 0.3A
- Contact Dc Max Rating R Load
- .3A@28VDC
- Switch Function
- On-On-On
- Orientation
- Straight
- Contact Current Rating
- 300mA
- Operating Force
- 200 ~ 600gf
- Voltage Rated Dc
- 28V
- Contact Materials
- Brass
- Actuator Length
- 4.00mm
- Ambalaj
- Bulk
