Specifications
- Parça Durumu
- Obsolete
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Current Rating Amps
- 300mA AC/DC
- Montaj
- Brackets, Through Hole
- Electricallife
- 10,000 Cycles
- Actuator Material
- Thermoplastic
- Terminal Stili
- PC Pin
- Contact Resistance
- 20mOhm
- Switch Type
- SLIDE SWITCH
- Pozisyon Sayısı
- 2
- Contact Ac Max Rating R Load
- .3A@125VAC
- Contact Currentdcmax
- 0.3A
- Actuator Type
- Standard
- Insulation Resistance
- 100000000Ohm
- Body Height
- 10mm
- Body Breadth
- 9.4 mm
- Contact Finish
- Silver
- Voltage Rated Ac
- 125V
- Dielectric Withstanding Voltage
- 500VRMS V
- Housing Material
- Steel
- Length Termination
- 0.118 inch
- Voltage Rated Dc
- 30V
- Switch Travel
- 2.00mm
- HTS Kodu
- 8536.50.90.50
- Çalışma Sıcaklığı
- -10°C~60°C
- Contact Dc Max Rating R Load
- .3A@30VDC
- Orientation
- Right Angle
- Actuator Length
- 7.00mm
- Terminal
- PC Pin
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Bulk
- Washability
- SOLVENT
- Additional Feature
- BIFURCATED WIPING CONTACT
- Pcb Hole Count
- 14
- Özellikler
- Epoxy Sealed Terminals
- Montaj Tipi
- Through Hole, Right Angle
- JESD-609 Kodu
- e4
- Contact Currentacmax
- 0.3A
- Seri
- MSS
