Specifications
- Contact Currentacmax
- 0.02A
- Circuit
- DPDT
- Seri
- MSS
- Özellikler
- Epoxy Sealed Terminals
- Pcb Hole Count
- 10
- Montaj Tipi
- Through Hole, Right Angle
- Electricallife
- 10,000 Cycles
- JESD-609 Kodu
- e4
- Montaj
- Through Hole
- Pozisyon Sayısı
- 2
- Contact Ac Max Rating R Load
- .02A@20VAC
- Actuator Material
- Thermoplastic
- Terminal Stili
- PC Pin
- Contact Timing
- Not Specified
- Contact Resistance
- 0.02mOhm
- Switch Type
- SLIDE SWITCH
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Obsolete
- Insulation Materials
- PHENOLIC
- Terminal
- PC Pin
- Ambalaj
- Bulk
- Washability
- SOLVENT
- Current Rating Amps
- 0.4VA AC/DC
- Additional Feature
- BIFURCATED WIPING CONTACT
- ECCN Kodu
- EAR99
- Body Length Or Diameter
- 16mm
- Contact Dc Max Power Rating R Load
- 0.4VA@20VDC
- Voltage Rated Ac
- 20V
- Dielectric Withstanding Voltage
- 500VRMS V
- Housing Material
- STEEL
- Length Termination
- 0.118 inch
- HTS Kodu
- 8536.50.90.50
- Çalışma Sıcaklığı
- -10°C~60°C
- Contact Dc Max Rating R Load
- .02A@20VDC
- Actuator Length
- 9.50mm
- Voltage Rated Dc
- 20V
- Switch Travel
- 2.00mm
- Switch Function
- On-On
- Actuator Type
- Standard
