Specifications
- Body Length Or Diameter
- 14mm
- Length Termination
- 0.118 inch
- Dielectric Withstanding Voltage
- 500VRMS V
- Voltage Rated Ac
- 125V
- Max Voltage Rating Dc
- 30V
- Housing Material
- Steel
- Contact Dc Max Rating R Load
- .3A@30VDC
- Actuator Length
- 2.30mm
- Orientation
- Straight
- HTS Kodu
- 8536.50.90.50
- Çalışma Sıcaklığı
- -10°C~60°C
- Switch Function
- On-On
- Switch Travel
- 2.00mm
- Voltage Rated Dc
- 30V
- Actuator Type
- Standard
- Sealing
- EPOXY TERMINAL SEALED
- Contact Currentdcmax
- 0.3A
- Contact Plating
- Silver
- Body Breadth
- 5.8 mm
- Body Height
- 10mm
- Insulation Resistance
- 100000000Ohm
- Seri
- MSS
- Circuit
- DPDT
- Akım Değeri
- 300mA
- Contact Currentacmax
- 0.3A
- Electricallife
- 10,000 Cycles
- JESD-609 Kodu
- e4
- Montaj
- Brackets, Through Hole
- Montaj Tipi
- Through Hole
- Pcb Hole Count
- 10
- Özellikler
- Epoxy Sealed Terminals
- Contact Ac Max Rating R Load
- .3A@125VAC
- Pozisyon Sayısı
- 2
- Contact Resistance
- 20mOhm
- Max Voltage Rating Ac
- 125V
- Switch Type
- SLIDE SWITCH
- Actuator Material
- Thermoplastic
- Terminal Stili
- PC Pin
- Contact Timing
- Not Specified
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
