Specifications
- Circuit
- SP3T
- HTS Kodu
- 8536.50.90.50
- Max Voltage Rating Dc
- 30V
- Pcb Hole Count
- 10
- Seri
- MSL
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- STEEL
- Current Rating Amps
- 200mA AC/DC
- Electricallife
- 10,000 Cycles
- Additional Feature
- BIFURCATED WIPING CONTACT
- Contact Timing
- Non-Shorting (BBM)
- Montaj
- Brackets, Through Hole
- Illumination Type
- Non-Illuminated
- Dielectric Withstanding Voltage
- 500VRMS V
- Body Length Or Diameter
- 28mm
- JESD-609 Kodu
- e4
- Özellikler
- Epoxy Sealed Terminals
- Switch Function
- On-On-On
- Contact Finish
- Silver
- Contact Style
- Non-Shorting
- Sealing
- EPOXY TERMINAL SEALED
- Body Height
- 10mm
- Max Voltage Rating Ac
- 125V
- Insulation Resistance
- 100000000Ohm
- Length Termination
- 0.118 inch
- Voltage Rated Ac
- 125V
- Parça Durumu
- Active
- Washability
- SOLVENT
- Contact Ac Max Rating R Load
- .2A@125VAC
- Montaj Tipi
- Through Hole
- Body Breadth
- 9.6 mm
- Pozisyon Sayısı
- 3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Force
- 250gf
- Actuator Length
- 14.20mm
- Akım Değeri
- 200mA
- Contact Dc Max Rating R Load
- .2A@30VDC
- Terminal Stili
- PC Pin
- Switch Type
- SLIDE SWITCH
- Insulation Materials
- PHENOLIC
