Volume pricing
- 1+ pcs$1.33
- 10+ pcs$1.25
- 100+ pcs$1.18
- 500+ pcs$1.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Body Breadth
- 3.5 mm
- Actuator Material
- Thermoplastic
- Switch Type
- SLIDE SWITCH
- Pcb Hole Count
- 4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Resistance
- 0.07mOhm
- Contact Timing
- Not Specified
- Parça Durumu
- Active
- Contact Dc Max Rating R Load
- .3A@6VDC
- Body Length Or Diameter
- 13mm
- Solderability
- WAVE
- Montaj Tipi
- Through Hole
- Contact Finish
- Silver
- Illumination Type
- Non-Illuminated
- Contact Currentdcmax
- 0.3A
- Electricallife
- 10,000 Cycles
- Terminal
- PC Pin
- Terminal Stili
- PC Pin
- Actuator Length
- 2.00mm
- Çalışma Sıcaklığı
- -10°C~60°C
- Voltage Rated Dc
- 6V
- Actuator Type
- Standard
- Current Rating Amps
- 300mA DC
- Pozisyon Sayısı
- 3
- JESD-609 Kodu
- e4
- ECCN Kodu
- EAR99
- Circuit
- SP3T
- Contact Current Rating
- 300mA
- Insulation Resistance
- 100000000Ohm
- Housing Material
- STAINLESS STEEL
- Additional Feature
- LOW PROFILE
- Switch Function
- On-On-On
- RoHS Durumu
- ROHS3 Compliant
- Length Termination
- 0.118 inch
- HTS Kodu
- 8536.50.90.50
- Sealing
- MOLDED
- Akım Değeri
- 300mA
- Body Height
- 3.5mm
- Fabrika Tedarik Süresi
- 8 Weeks
- Ambalaj
- Bulk
