Specifications
- Voltage Rated Dc
- 30V
- Actuator Length
- 2.00mm
- Montaj
- Through Hole
- Akım Değeri
- 300mA
- RoHS Durumu
- ROHS3 Compliant
- Orientation
- Straight
- Switch Type
- SLIDE SWITCH
- Contact Finish
- Silver
- Body Length Or Diameter
- 16mm
- Max Voltage Rating Dc
- 30V
- Contact Resistance
- 25mOhm
- Fabrika Tedarik Süresi
- 8 Weeks
- Seri
- MMS
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Material
- Polybutylene Terephthalate (PBT)
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Contact Dc Max Rating R Load
- .3A@30VDC
- Montaj Tipi
- Through Hole
- Contact Currentdcmax
- 0.3A
- Terminal Stili
- PC Pin
- Additional Feature
- LOW PROFILE
- JESD-609 Kodu
- e4
- Body Breadth
- 7 mm
- Sealing
- EPOXY TERMINAL SEALED
- Contact Current Rating
- 300mA
- HTS Kodu
- 8536.50.90.50
- Actuator Type
- Standard
- Circuit
- 4PDT
- Parça Durumu
- Active
- Özellikler
- Epoxy Sealed Terminals
- Current Rating Amps
- 300mA DC
- Çalışma Sıcaklığı
- -20°C~70°C
- Switch Function
- On-On
- Contact Timing
- Not Specified
- Electricallife
- 10,000 Cycles
- Body Height
- 5.5mm
- Terminal
- PC Pin
