Volume pricing
- 1+ pcs$0.22
- 10+ pcs$0.21
- 100+ pcs$0.20
- 500+ pcs$0.19
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- PC Pin
- Max Voltage Rating Dc
- 12V
- Circuit
- SPST-NO
- Contact Bounce Timemax
- 10ms
- Actuator Orientation
- Top Actuated
- Actuator Material
- Thermoplastic
- Body Breadth
- 6 mm
- Operating Force
- 160gf
- HTS Kodu
- 8536.50.90.40
- Terminal Material
- BRASS
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Length Termination
- 0.138 inch
- Montaj
- Through Hole
- Contact Resistance
- 100mOhm
- Dielectric Withstanding Voltage
- 250VAC V
- Voltage Rated Dc
- 12V
- Actuator Height Off Pcb Vertical
- 8.00mm
- JESD-609 Kodu
- e4
- Mechanical Life
- 100,000 Cycles
- Çalışma Sıcaklığı
- -20°C~70°C
- Outline
- 6.00mm x 6.00mm
- Number Of Switches
- 1
- Switch Type
- KEYPAD SWITCH
- Seri
- MJTP
- Switch Travel
- 0.25mm
- Pcb Hole Count
- 5
- Contact Plating
- Silver
- Electricallife
- 100000 cycles
- RoHS Durumu
- ROHS3 Compliant
- Orientation
- Straight
- Akım Değeri
- 50mA
- Switch Function
- Off-Mom
- Contact Materials
- Bronze, Stainless Steel
- Actuator Type
- Standard
- Body Height
- 4.1mm
- Contact Rating Voltage
- 0.05A @ 12VDC
- Fabrika Tedarik Süresi
- 6 Weeks
- ECCN Kodu
- EAR99
- Contact Currentdcmax
- 0.05A
- Actuator Length
- 4.4mm
