Specifications
- Switch Travel
- 2.00mm
- Montaj Tipi
- Through Hole, Right Angle
- Seri
- MJS
- Parça Durumu
- Obsolete
- Ambalaj
- Bulk
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 100mA
- Electricallife
- 10,000 Cycles
- Sealing
- MOLDED
- Pcb Hole Count
- 6
- Çalışma Sıcaklığı
- -10°C~60°C
- Contact Timing
- Not Specified
- Voltage Rated Dc
- 12V
- Pozisyon Sayısı
- 2
- JESD-609 Kodu
- e4
- Dielectric Withstanding Voltage
- 500VRMS V
- Contact Dc Max Rating R Load
- .1A@12VDC
- Switch Type
- SLIDE SWITCH
- Insulation Resistance
- 100000000Ohm
- Washability
- PARTIAL
- Illumination Type
- Non-Illuminated
- Terminal
- PC Pin
- Actuator Length
- 2.50mm
- Contact Currentdcmax
- 0.1A
- ECCN Kodu
- EAR99
- Insulation Materials
- PHENOLIC
- Current Rating Amps
- 100mA DC
- HTS Kodu
- 8536.50.90.50
- Operating Force
- 225gf
- Body Breadth
- 6 mm
- Body Length Or Diameter
- 10mm
- Contact Resistance
- 0.02mOhm
- Montaj
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Length Termination
- 0.118 inch
- Solderability
- WAVE
- Circuit
- DPDT
- Contact Finish
- Silver
- Akım Değeri
- 100mA
- Terminal Stili
- PC Pin
