Specifications
- Electricallife
- 10,000 Cycles
- RoHS Durumu
- RoHS Compliant
- Pcb Hole Count
- 3
- Sealing
- MOLDED
- Montaj Tipi
- Through Hole, Right Angle
- Switch Travel
- 2.00mm
- Parça Durumu
- Obsolete
- Ambalaj
- Bulk
- Seri
- MJS
- Switch Type
- SLIDE SWITCH
- Insulation Resistance
- 100000000Ohm
- Terminal
- PC Pin
- Washability
- PARTIAL
- Illumination Type
- Non-Illuminated
- JESD-609 Kodu
- e4
- Voltage Rated Dc
- 12V
- Pozisyon Sayısı
- 2
- Çalışma Sıcaklığı
- -10°C~60°C
- Contact Timing
- Not Specified
- Contact Dc Max Rating R Load
- .1A@12VDC
- Dielectric Withstanding Voltage
- 500VRMS V
- Body Length Or Diameter
- 10.2mm
- Contact Resistance
- 20mOhm
- Solderability
- WAVE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Length Termination
- 0.118 inch
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Contact Currentdcmax
- 0.1A
- Actuator Length
- 2.50mm
- Body Breadth
- 4 mm
- Operating Force
- 225gf
- Current Rating Amps
- 100mA DC
- HTS Kodu
- 8536.50.90.50
- Insulation Materials
- PHENOLIC
- Body Height
- 5mm
- Actuator Material
- Thermoplastic
- Switch Function
- On-On
- Actuator Type
- Standard
- Contact Finish
- Silver
