Specifications
- Contact Timing
- Not Specified
- Çalışma Sıcaklığı
- -10°C~60°C
- Pozisyon Sayısı
- 2
- Voltage Rated Dc
- 12V
- JESD-609 Kodu
- e4
- Dielectric Withstanding Voltage
- 500VRMS V
- Voltage Rated Ac
- 12V
- Contact Dc Max Rating R Load
- .1A@12VDC
- Insulation Resistance
- 100000000Ohm
- Switch Type
- SLIDE SWITCH
- Washability
- PARTIAL
- Illumination Type
- Non-Illuminated
- Terminal
- PC Pin
- Montaj Tipi
- Through Hole
- Seri
- MJS
- Ambalaj
- Bulk
- Parça Durumu
- Obsolete
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 100mA
- Electricallife
- 10,000 Cycles
- Sealing
- MOLDED
- Pcb Hole Count
- 3
- Circuit
- SPDT
- Akım Değeri
- 100mA
- Contact Finish
- Silver
- Terminal Stili
- PC Pin
- Actuator Material
- Thermoplastic
- Body Height
- 4.5mm
- Actuator Type
- Standard
- Switch Function
- On-On
- Actuator Length
- 2.00mm
- Contact Currentdcmax
- 0.1A
- ECCN Kodu
- EAR99
- Insulation Materials
- PHENOLIC
- HTS Kodu
- 8536.50.90.50
- Current Rating Amps
- 100mA DC
- Body Breadth
- 4 mm
- Operating Force
- 225gf
- Contact Resistance
- 0.02mOhm
- Body Length Or Diameter
- 10.2mm
